Description
x|
MZ-5800 |
||
|
Range |
5.5-5.8m （One Tele） |
|
|
Lifting force at crane nose at reach |
2M |
1800kg |
|
5.8M |
650kg |
|
|
Column torque |
11 KN. m |
|
|
Column rotating structure |
Flange+ Rack and pinion cylinder (Partial carburizing process) |
|
|
Rotating cylinder |
4pcs (Italy oil seal) |
|
|
Rotation angle |
380° (L 190°+R 190°) |
|
|
H-type outriggers |
2 pcs hydraulic outriggers (Can be equipped with different outriggers according to the vehicle) |
|
|
Grip |
360° unrestricted rotation |
|
|
Boom structure |
Two sections foldable, one section telescopic |
|
|
Weight |
900 kg |
|
|
Installation space |
500 mm |
|
|
Hydraulic flow |
40 L/min |
|
|
Recommended power |
11 KW |
|
|
Customization available for different needs |
Aluminum hydraulic cylinder, High power 150L radiator (Temperature-controlled automatic start/stop), High pressure pump, Hydraulic outriggers 2pcs, Hydraulic lock 2pcs, Mounting bolts, Mounting plate. |
|
