Structural features:
● Advanced end-face flow distribution design, smooth rotation at low speed.
● Advanced shaft seal design, can withstand high back pressure.
● Advanced oil distribution mechanism design, with automatic wear compensation function.
● Double row tapered roller bearing design can withstand large radial force.
● A variety of flange, output shaft, and other installation and connection forms.
1. Discontinuous refers to the maximum pressure at the entrance, and continuous working pressure refers to the difference of working pressure.
2. The motor works at the same time under the highest pressure and the highest leakage.
3. The running time of the motor should not exceed 10% under intermittent working conditions.
4. Maximum operating temperature 80*.
5. The maximum allowable back pressure of the motor is 10MPa, but it is recommended that the back pressure should not exceed 5MPa. In case of excess, it should be connected to the leakage pipe.
6. It is recommended to operate the motor under 40% of the maximum pressure for 1 hour before full load operation
7. Recommended use of 68# anti-wear hydraulic oil, viscosity 37-73CST, cleanliness IS018/13.
