Structural features:
● The design of fixed rotor with inserted column, high oil distribution accuracy and mechanical efficiency.
● Imported shaft seal, can withstand high back pressure.
● A variety of oil port, flange, output shaft and other connection forms.
● Steady speed, easy to reverse and reverse conversion.
● Small volume, compact structure.
1. Discontinuous refers to the maximum pressure at the entrance, and continuous working pressure refers to the difference of working pressure.
2. The motor should not work under the highest pressure and the highest speed at the same time.
3. The running time of the motor should not exceed 10% under intermittent working conditions.
4. Maximum operating temperature 80°.
5. The maximum allowable back pressure of the motor is 10MPa, but it is recommended that the back pressure should not exceed 5MPa. If the back pressure exceeds 5MPa, the leakage pipe should be connected.
6. It is recommended to run the motor under 40% of the maximum working pressure for 1 hour before working at full load.
7. It is recommended to use 68# anti-wear hydraulic oil, viscosity 37-73CST, cleanliness ISO18/13.
