Structure features: advanced end-face flow distribution design, smooth rotation at low speed. Advanced shaft seal design, can withstand high back pressure.
Advanced oil distribution mechanism design, with automatic wear compensation function. Double row tapered roller bearings are designed to withstand large radial forces, a variety of flanges, output shafts, and other mounting connections.
1, intermittent refers to the maximum inlet pressure, continuous working pressure refers to the working pressure difference 2, the motor should not work at the same time under the highest pressure and maximum speed.
3, the motor in intermittent working conditions, the running time should not exceed 10%.
4. The maximum working temperature is 8085 and the maximum allowable back pressure of the motor is 10MPa. However, it is recommended that the back pressure should not exceed SMPa
6. It is recommended to assemble below 40% of the maximum working pressure for 1 hour before the motor works at full load.
7, the recommended use of 68# anti-wear hydraulic oil, viscosity 37-73CST, cleanliness ISO18/13
