YOJU FWA/FWB series Slew Drive has Enclosed housing and Shaft seals, and Ingress Protection can reach IP65, which can effectively prevent dust and water from entering the Slew Drive, requiring less maintenance.
YOJU has the special worm gear technology, material, and surface heat treatment process, FWA/FWB series can output super torque, more wear-resistant and longer working life.
● Enclosed housing with shaft seals for improved sealing capability up to IP65;
● Specially designed and heat treated worm gear and worm shaft;
● 360° Clockwise and counterclockwise continuous rotation;
● Self-locking/non-self-locking worm gear optional;
● Metric or British optional, Customizable Installation size and input interface;
● Single worm shaft and Double worm shaft optional, Double Torque;
| Output Torque | Tilting Moment Torque | Holding Torque | Axial Load | Radial Load | Ratio | Backlash | Weight |
| 34.2 KN.M | 310 KN.M | 160 KN.M | 2400 KN | 950 KN | 104:1 | ≤0.1° | 200Kg |
| 25240 Ibf.Ft | 229x10³ Ibf.Ft | 118x10³ Ibf.Ft | 539.5x10³ Ibf | 213.6x10³ Ibf |
