CA50 series hydraulic motors

CA series hydraulic motor is a new product developed by our company for high-end market, the product can work in all kinds of bad working conditions is stable, can meet most of the cases of hydraulic motor with high working pressure, stability and low speed high torque output, such as requirements, on the structure, the motor adopts face with flow, radial piston curve within the form, taking the advantages of the motor rotor hollow, It is convenient to configure brakes, speed detectors, and special equipment through the hole in the motor according to the user's requirements, which greatly simplifies the requirements of the user on the host structure. Its main characteristics are as follows:

Strong impact resistance and good stability;

A safe and stable variable and parking braking;

One can realize free wheel working condition;

A variety of installation methods and hollow shaft design;

Large output torque, wide speed range, can directly replace high-speed motor reducer device, compact structure (small volume);

One has good low-speed stability, can run smoothly at a very low speed;

High mechanical efficiency and volume efficiency;

The direction of rotation is reversible;

A high power quality ratio;

A good reliability, easy maintenance.

Motor features:

1. Modular design

The overall structure according to the modular design, chip stacked, divided into mechanical output device, hydraulic function device, mechanical brake device three parts, so it can be convenient with all kinds of host optimization matching.

2. High efficiency

Multi-action plane flow distribution technology, low sensitivity to pressure and temperature, automatic compensation of the wear between the flow distribution friction pair, so as to ensure a long period of high volume efficiency of the motor, while using roller, plunger structure, simple force transmission, less friction pair, improve the mechanical efficiency.

3. High working pressure, good low speed performance, with free wheel working condition

High pressure up to 40Mpa, due to the small inertia of the force transmission mechanism, the plunger pair is sealed by the plunger ring, so the start-up efficiency is high, the track hydraulic motor has good low-speed performance, low stable speed ≤ 0.5RPmA

4. Can bear radial and axial load

Adopt independent setting mechanical output device, bearing and output shaft diameter size are large, and hydraulic function device radial force balance is output by pure torque so the motor can withstand large axial force and radial force, can be direct gear output or directly arranged on the vehicle drive wheel.

5. Mechanical brake is available

Adopting fan hydraulic motor modular chip structure, superimposed mechanical braking device is very simple to realize direct safety braking and parking braking of output shaft.
