Structural characteristics of
Adopt column fixed rotor design, with higher oil distribution accuracy and mechanical efficiency double rolling bearing design, can withstand higher lateral force inlet shaft seal design, bear high back pressure, can be in series and parallel use positive and negative conversion to convenient, stable speed
A variety of oil port, output shaft, flange and other connection forms
1, intermittent refers to the maximum pressure at the entrance, continuous working pressure refers to the working pressure difference.
2, the motor should not work at the same time under the highest pressure and the highest speed.
3, the motor in intermittent working conditions, the running time should not exceed 10%.
4. The highest working temperature is 80°
5. The maximum allowable back pressure of the motor is 10MPa, but it is recommended not to exceed it.
5MPa, when exceeding, it shall be connected to the external berthing pipe.
6. It is recommended to run the motor under 40% of the maximum working pressure for 1 hour before working at full load.
7, recommended use of 68# anti-wear hydraulic mooring, viscosity 37-73CST, cleanliness ISO18/13.
